C-14 Fully Hydraulic Multi-Functional Drilling Rig

Short Description:

The C-14 full-hydraulic multifunctional ground improvement equipment is designed for small-section tunnels and coal mine roadways. It integrates drilling, water stopping, drainage, and grouting functions. With a full-hydraulic drive system, it adapts well to complex environments and enables multi-angle operations (vertical, horizontal, inclined). Its intuitive interface allows quick parameter adjustment even in narrow spaces, enhancing efficiency and safety in underground projects. It is an ideal solution for ground reinforcement and hydrological control in mines and tunnels.

rotary drilling rig, bore pile machine, Construction Machinery

Product Detail

Product Advantages

All-Round, Multi-Angle Construction Capability

Supports vertical, horizontal, and inclined operations; adapts to small-section tunnels/coal mine roadways, meets drilling/water stopping/drainage/grouting needs, and enhances narrow-space adaptability.

Modular Power Head & Mast Design

Comes with replaceable modules; switches per geological conditions/construction goals for “one machine, multiple uses,” cutting equipment costs and boosting efficiency.

Diesel-Driven Power System

Diesel engine as core power source; ensures stable high-torque output in power-limited mines/ tunnels, balances fuel efficiency for long continuous operations.

Load-Sensing Hydraulic System

Adopts load-sensing control; adjusts pressure/flow in real time to avoid energy waste, reduces oil temperature, extends component life, and meets green construction requirements.

Working Configuration

Parameter table

Undercarriage
Type	pivoting+/-10°
Triple grouser track shoe width	400 mm
Overall length	3130 mm
Overall width (not extendable crawler)	2300 mm
Travelling speed	2.7 km/h
Average ground pressure	0.070 MPa
Ground stabilizers	2 fixed on rear
Diesel Engine
Diesel engine power rating	119kW@2200 rpm
Fuel tank capacity	200 L
Hydraulic System
Main pumps:variable axial pumps	156+156 L/min
Auxiliary pumps:gear pumps	20 L/min
Hydraulic oil tank capacity	400 L
Rotary head
Model	QX1300Vh	GLM260	HG120	HG170
Transmission Type	Variable Motor+ Two-speed Gear Transmission	Variable Motor+ Two-speed Gear Transmission	Variable Motor	Variable Motor
Torque Parameter	3900N ·m @ 112rpm	7800N ·m @ 56rpm	10037N ·m @ 45rpm	10037N ·m @ 45rpm
	2440N ·m @ 180rpm	3900N ·m @ 112rpm	6273N ·m @ 72rpm	6273N ·m @ 72rpm
Maximum Drilling Speed	360rpm	224rpm	72rpm	72rpm
Connection Type	Top Drive 50~114mm	Top Drive 150- 219mm	Hollow Shaft 124mm	Hollow Shaft 170mm
Clamp &Hydraulic Joint breaker
Nominal size	50-315/60-415 mm
Maximum clamping force	268kN
Maximum breaking torque	5060 daNm
Pull-up extractor clamp force/stroke	100 kN/400 mm
Service winch
1°layer line pull	24kN
Rope diameter	10 mm
Rope speed	46 m/min
Hoist &Feed System
Feed Stroke	4300mm
Max Hoist pull	99kN
Max Feed force	99kN
Max speed fast/low	28/5 m/min
